MCH-30 Temperature Controlled Dehumidifier

Dehumidification Capacity: 720 L/day (1500 PPD)
Cooling Capacity: 40 kW
Heating Capacity: 15 kW
Indoor Unit Dimensions: 1300 × 680 × 1920 mm
Large-Space Control: Designed for production and storage areas requiring stronger temperature and humidity adjustment.
High-Volume Airflow: 6000 m³/h airflow with 200 Pa pressure supports wider coverage.

Product Parameters

Model	Dehumidification Capacity (30°C, 90% RH)	Cooling Capacity	Heating Capacity	Power Supply
MCH-30	720 L/day (1500 PPD)	40 kW	15 kW	3N~380V / 50Hz
Airflow	External Static Pressure	Operating Temperature	Refrigerant	Control Mode
6000 m³/h	200 Pa	5°C–38°C	R410A	Microcomputer Automatic Control
Airflow Direction	Indoor Unit Dimensions (L×W×H)	Indoor Unit Weight	Outdoor Unit Dimensions (L×W×H)	Outdoor Unit Weight
Front Air Inlet / Top Air Outlet	1300 × 680 × 1920 mm	Not Provided	1300 × 700 × 900 mm	Not Provided
Humidity Display	Automatic Defrost	Humidity Control	Timer Control	Protection & Alarm
LED Temperature & Humidity Display	Automatic	Automatic Humidity Control	Timed On/Off	Phase Protection & Fault Alarm
Compressor	Fan	Humidity Sensor	Heat Exchanger	Controller
HIGHLY Compressor	Zhejiang Jiale Centrifugal Fan (6000 m³/h, 200 Pa)	Hokuriku, Japan Electronic Sensor	OAK Heat Exchanger with Copper Tubes and Aluminum Fins	Xiangtai Microcomputer Controller
